General Programming 6-41
September 2007
ANALOG GROUND INPUT
Option
The Analog Ground Input option lets you monitor the analog ground
input signal. The acceptable range for this signal is -1 mV to +10 mV.
The current Analog Ground Input signal is displayed.
This completes the prompts for the Analog Ground Input option, and
the XMO2 returns to the Test Inputs? menu.
DONE? Option The Done? option is used to exit the Test Inputs? submenu and return
to the main General menu. At the next prompt, the following two
responses are available:
• Yes - exit immediately to the main General menu
• No - remain in the Test Inputs? submenu
This completes the prompts for the Done? option. Go to the
appropriate section of this chapter, based on the selection made
above, for further programming instructions.
TEST INPUTS
Press [Y] or [Enter] to view the
Analog Ground input, or press
[N] to move to the next Test
Inputs? option.
Analog Ground Input?
Analog Ground Input
When ready, press any key to
return to the Test Inputs? menu:
-x.x Agnd mV
TEST INPUTS
Press [Y] or [Enter] to return to
the main General menu, or press
[N] to remain in the Test Inputs?
submenu.
Done?
