September 2007
5-4 Basic Programming
Entering the Basic Menu To switch the XMO2 from Operate Mode to Programming Mode,
proceed as follows:
Note: If the XMO2 is set up for Easy Menu Entry, pressing
[Shift]+[1]
switches the XMO2 directly to Programming Mode and enters
the Basic Menu. See Chapter 7, Advanced Programming, for
instructions on setting up Easy Menu Entry.
Note: An * is displayed after each digit is entered. If you enter an
incorrect code, press a non-numeric key, or press the keys too
quickly, the XMO2 will return to Operate Mode.
Note: The exact Menu Option? shown at the above prompt depends
on the current settings in the XMO2 program.
Basic Menu Options The Basic Menu, which is accessed as described on page 5-4,
includes eight possible menu options. Of the eight possible options, a
total of 3, 5 or 6 can appear at any one time. The specific options and
when they are available are determined as shown in Table 5-1 below.
Note: DriftCal Handler and the Number of Gases are specified in
the General Menu (see Chapter 6, General Programming).
Proceed to the appropriate section to program the desired option.
xx.xx %O2
Press [Y] or [ENTER].
Enter Code:
Press the [1], [2], and [3] keys
slowly and firmly, in sequence.
BASIC MENU
Menu Option?
Table 5-1: Available Menu Options
Option DriftCal Status # Cal. Gases
Quick Offset ON 1
View Offset ON 1
Quick Zero ON 2
Quick Span ON 2
View Drift Curve ON 2
Set Low Input Value ON or OFF 1 or 2
Set High Input Value ON or OFF 1 or 2
Resume ON or OFF 1 or 2
