September 2007
7-16 Advanced Programming
GAS VALUE EXP FILTER
Option (cont.)
The Done option:
The Done? option returns the XMO2 to the Calibrate System menu
from the Gas Value Exp Filter? submenu. To use this option, refer to
the menu map in Figure C-8 on page C-8 and press
[N] until the
following prompt appears.
You may now do one of the following:
• Press [N] as many times as necessary to select another desired Gas
Value Exp Filter? option. Then, press
[Y] and proceed to the
appropriate section for instructions.
• Press [Y] to leave the Gas Value Exp Filter? submenu and return to
the top level of the Calibrate System menu.
GAS mV EXP FILTER Option The Gas mV Exp Filter? option is used to specify the five parameters
associated with the XMO2’s fast response algorithm for the main gas
when background gas compensation is enabled. To use this option,
refer to the menu map in Figure C-8 on page C-8 and proceed as
follows:
IMPORTANT: The fast response parameters are set up at the
factory, and should not need to be changed. If you
are having problems with the fast response option,
consult the factory before making any changes.
Note: This menu option appears only if Response Type is Fast and
Background Compensation is ON.
The Gas mV Exp Filter? submenu includes the same six options as
the Gas Value Exp Filter? submenu, except that the values are in mV
instead of %. See the descriptions of these options on pages 7-12
through 7-16.
Proceed to the appropriate section for programming instructions.
Gas Value Exp Filter:
Respond as indicated below.
Done?
CALIBRATE SYSTEM
Press [N] until this prompt
appears, then press
[Y] or [Enter].
Gas mV Exp Filter?
To Next Page
