Advanced Programming 7-17
September 2007
COMP mV EXP FILTER
Option
The Comp mV Exp Filter? option is used to specify the five
parameters associated with the XMO2’s fast response algorithm for
the background gas when background gas compensation is enabled.
To use this option, refer to the menu map in Figure C-8 on page C-8
and proceed as follows:
IMPORTANT: The fast response parameters are set up at the
factory, and should not need to be changed. If you
are having problems with the fast response option,
consult the factory before making any changes.
Note: This menu option appears only if Response Type is Fast and
Background Compensation is ON.
The Comp mV Exp Filter? submenu includes the same six options as
the Gas mV Exp Filter? submenu, except that the values are for the
background gas instead of the main gas. See the descriptions of these
options on pages 7-12 through 7-16.
Proceed to the appropriate section for programming instructions.
DRIFTCAL HANDLER
Option
The DriftCal Handler? option is used to specify the maximum total
drift and the maximum drift per calibration for the DriftCal Handler
algorithm. To use the DrifCal Handler? option, refer to the menu map
in Figure C-8 on page C-8 and complete the following steps:
Note: See Chapter 6, General Programming, for a variety of other
options related to calibration of the XMO2.
The DriftCal Handler? submenu includes the following options:
• Set Max Total Drift
• Set Max Drift/Cal
• Done
Proceed to the appropriate section for programming instructions.
CALIBRATE SYSTEM
Press [N] until this prompt
appears, then press
[Y] or [Enter].
Comp mV Exp Filter?
CALIBRATE SYSTEM
Press [N] until this prompt
appears, then press
[Y] or [Enter].
DriftCal Handler?
