7-20 Advanced Programming
DONE Option The Done? option returns the XMO2 to the Advanced main menu
from the Calibrate System? submenu. To use this option, refer to the
menu map in Figure C-7 on page C-7 and press
[N] until the following
prompt appears.
You may now do one of the following:
• Press [N] as many times as necessary to select another desired
Calibrate System? option. Then, press
[Y] and proceed to the
appropriate section for instructions.
• Press [Y] to leave the Calibrate System? submenu and return to the
top level of the Advanced menu.
CALIBRATE RECORDER
Menu
The Calibrate Recorder? menu is used to electronically calibrate the
4-20 mA analog output circuit. Refer to Figure C-8 on page C-8 and
enter this menu from the Advanced Menu prompt as follows:
Note: This calibration is independent of the 4-20 mA analog output
calibration described in Chapter 4, Field Calibration. That
procedure uses zero/span gases and internal potentiometer
adjustments to calibrate the XMO2’s 4-20 mA analog output
for those gases.
CALIBRATE SYSTEM
Respond as indicated below.
Done?
ADVANCED MENU
Press [N] until this prompt
appears, then press
[Y] or [Enter].
Calibrate Recorder?
CALIBRATE RECORDER
Press [Y] or [Enter] to force the
analog output to exactly 4 mA.
Read LabCal 4 mA?
Enter mA Output Zero:
Use the numeric keys to enter the
mA value shown on the output
device. Then, press
[Y] or [Enter].
mA [x.xx]
CALIBRATE RECORDER
Press [Y] or [Enter] to force the
analog output to exactly 20 mA.
Read LabCal 20 mA?
Enter mA Output Span:
Use the numeric keys to enter the
mA value shown on the output
device. Then, press
[Y] or [Enter].
mA [xx.xx]
