September 2007
2-10 Installation
TMO2D Display The GE TMO2D display provides a two-line x 24 character back-lit
LCD. It features display and option programming via the keyboard
and it offers recorder outputs, alarm relays, and optional relays for
driving sample system solenoids for automatic zero and span
calibration of the XMO2. See Figure B-3 on page B-3 for an
interconnection diagram, and refer to the TMO2D Users Manual
(910-084) for details on its operation.
LDP Display The LDP display provides an integral, regulated 24 VDC power
supply, an adjustable 3-digit display to program the 4-20 mA analog
input range, two programmable SPDT alarm relays rated for 1A
@250 VAC, and an isolated, independently-adjustable 4-20 mA
analog output. The LDP is supplied in an explosion-proof enclosure
that is rated for Cenelec EEx d IIC T6 and IP66 (with an optional
gasket). See Figure B-3 on page B-3 for an interconnection diagram,
and refer to the LDP Users Manual (910-225) for details on its
operation.
XDP Display The XDP Explosion-proof Display Package provides an integral,
regulated 24 VDC power supply, a 3-digit display with an adjustable
4-20 mA analog input range, two SPDT alarm relays rated for 1A
@250 VAC, and an isolated, independently-adjustable 4-20 mA
analog output. The XDP is supplied in an explosion-proof enclosure
that is rated for Cenelec EEx d IIC T6 (approval pending) and IP66
(with optional gasket). See Figure B-3 on page B-3 for an
interconnection diagram, and refer to the XDP Users Manual (910-
204) for details on its operation.
Moisture Image/Monitor
Series Analyzers
These GE instruments include the Moisture Image Series 1, Moisture
Image Series 2, and Moisture Monitor Series 3 analyzers. These
analyzers accept inputs from a variety of sensors (including the
XMO2) and offer graphical and digital interfaces. See Figure B-3 on
page B-3 for interconnection diagrams, and refer to the Users
Manual (910-108, 109, or 110) for details on its operation.
Note: An external 24 VDC power supply (such as the PS5R-C24) is
required to use the XMO2 with these analyzers.
System 1 Analyzer The GE System 1 is a versatile multi-channel analyzer which accepts
inputs from any combination of GE moisture, temperature, oxygen,
and thermal conductivity transmitters. See Figure B-3 on page B-3 for
an interconnection diagram, and refer to the System 1 Users Manual
(900-019) for details on its operation.
Note: An external 24 VDC power supply (such as the PS5R-C24) is
required to use the XMO2 with the System 1 analyzer.
