GE XMO2 User Manual

Advanced Programming 7-11
September 2007
O2 INPUT Option (cont.) The Done option:
The Done? option returns the XMO2 to the Calibrate System menu
from the O2 Input? submenu. To use this option, refer to the menu
map in Figure C-8 on page C-8 and press
[N] until the following
prompt appears.
You may now do one of the following:
• Press [N] as many times as necessary to select another desired O2
Input? option. Then, press
[Y] and proceed to the appropriate
section for instructions.
• Press [Y] to leave the O2 Input? submenu and return to the top
level of the Calibrate System menu.
COMP INPUT Option The Comp Input? option is used to specify a shutoff value in mV for
the background gas compensation signal (the factory default value is
150.0 mV). To use this option, refer Figure C-8 on page C-8 and
proceed as follows:
Note: This option appears only if Background Compensation is ON.
You may now do one of the following:
• Press [N] as many times as necessary to select another O2 Input
menu option. Then, press
[Y] and proceed to the appropriate
section of this chapter for instructions.
• Press [N] until you reach the Done? option of the O2 Input menu,
then press
[Y] to return to the Calibrate System main menu.
Adjust Zero:
Respond as indicated below.
Done?
CALIBRATE SYSTEM
Press [N] until this prompt
appears, then press
[Y] or [Enter].
Comp Input?
Enter Shutoff Value:
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
mV [xxx.x]
CALIBRATE SYSTEM
You have now completed the
programming of this submenu.
Comp Input?
