September 2007
6-42 General Programming
TEST RECORDER Menu The Test Recorder? option lets you check the accuracy of the XMO2
4-20 mA analog output. To use this option, refer to the menu map in
Figure C-6 on page C-6, and proceed as follows:
Note: Before testing the 4-20 mA analog output, be sure the output is
properly scaled (see pages 5-10 to 5-11, or see page 6-36) and
calibrated (see page 7-32).
The next prompt lists whichever choice was selected the last time the
menu was accessed:
• Enter mA - tests the 4-20 mA output to a specified mA value
• Enter Units - tests the 4-20 mA output to a specified % oxygen
Based on the selection made above, go to the appropriate section.
ENTER mA Option If you selected the Enter mA? option, enter the desired analog output
in mA at the next prompt.
The 4-20 mA analog output is forced to the value specified above.
Verify that your analog output device is displaying the correct value.
This completes the prompts for the Enter mA? option, and the XMO2
returns to the main General menu.
GENERAL MENU
Press [Y] or [Enter] to enter the
Test Recorder? menu, or press
[N]
to move to the next General
Menu option.
Test Recorder?
Select Value Type:
Press [N] until the desired option
is displayed, then press
[Y] or
[Enter] to proceed.
(Enter mA?) or (Enter Units?)
Enter mA Output mA:
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
mA [xx.xx]:
mA Output @ xx.xx mA
When ready, press [Y] or [Enter]
to return to the General menu:
Press [YES]
To Next Page
