100
4. CONFIGURATION
4.16.1. OUT.N - Selecting the output
Acronym Scrolling message Submenu Attributes
OUT.N OUTPUT NUMBER OUTPU R W
The parameter shows and sets the identifying number of the output to be configured.
Unit of measurement: Number
Options: 1...4
4.16.2. S.ou.x - Defining the output state
Acronym Scrolling message Submenu Attributes
S.ou.x DIGITAL OUTPUT STATUS OUTPU R W
The parameter shows and sets the state of the output with identifying number “x”.
The active direct output corresponds to the relay, logic, or trial output ON (conducting).
The active inverse output corresponds to the relay, logic, or trial output OFF.
If the output is continuous, direct corresponds to minimum = 4mA and maximum = 20 mA, while inverse corresponds to
minimum = 20 mA and maximum = 4 mA.
The outputs can be forced so that they are always on or off.
Unit of measurement: -
Options: DIREC = Direct output
INVRS = Inverse output
OFF = Output forced off
ON = Output forced on
