57
4. CONFIGURATION
4.6.1. PR.STP - Programming step
Acronym Scrolling message Submenu Attributes
PR.STP PROGRAMMER ACTUAL STEP PR.SPT R W
The parameter shows and sets the number of the programming step being configured.
Unit of measurement: Step number
Options: 1...12
4.6.2. SETP - Programming step setpoint
Acronym Scrolling message Submenu Attributes
SETP STEP SETPOINT PR.SPT R W
The parameter shows and sets the setpoint for the current programming step.
The selectable values are between the low setpoint (LO.SP) and the high setpoint (HI.SP), settable with submenu
I.MAIN.
Unit of measurement: °C, °F, % based on chosen scale
Options: LO.SP...HI.SP
4.6.3. RAMP.T - Step time ramp
Acronym Scrolling message Submenu Attributes
RAMP.T STEP RAMP TIME PR.SPT R W
The parameter shows and sets the time taken to go from the previous setpoint to the setpoint of the current programming
step.
Unit of measurement: hh.mm or mm.ss (hours.minutes or minutes.seconds). Depends on time base set with
submenu MODE, parameter t.Pro
Options: 00.00...99.59
4.6.4. HOLD.T - Hold time in step
Acronym Scrolling message Submenu Attributes
HOLD.T STEP HOLD TIME PR.SPT R W
The parameter shows and sets the time the program waits before going to the next step.
Unit of measurement: hh.mm or mm.ss (ore.minuti o minuti.secondi). Depends on time base set with submenu MODE,
parameter t.Pro
Options: 00.00...99.59
4.6.5. HBB - Enable Hold Back Band function
Acronym Scrolling message Submenu Attributes
HBB HOLD BACK BAND FUNCTION PR.SPT R W
The parameter enables and disables the Hold Back Band function
The HBB function checks that the variable remains in the required tolerance interval. If the maximum deviation is excee-
ded, the program time base is stopped. The function is settable independently for each programming step. In addition, it
can be enabled for the time ramp only, for the hold time only, or for both.
Unit of measurement: -
Options: OFF = Disables HBB function
On = Enables HBB function
