4. CONFIGURATION
4.17.1. S.o.A1 - Defining the state of the analog output
Acronym Scrolling message Submenu Attributes
S.o.A1 ANALOG OUTPUT STATUS OUT.AN R W
The parameter shows and sets the state of analog retransmission output A1.
The active direct output corresponds to minimum with the minimum output value in voltage or current.
The active inverse output corresponds to minimum with the maximum output value in voltage or current.
The outputs can be forced so that they are always on or off.
Unit of measurement: -
Options: DIREC = Direct output
INVRS = Inverse output
OFF = Forced output inactive (minimum voltage or current value)
ON = Forced output active (maximum voltage or current value)
4.17.2. t.o.A1 - Defining the type of analog output
Acronym Scrolling message Submenu Attributes
t.o.A1 ANALOG OUTPUT TYPE OUT.AN R W
The parameter shows and sets the definition of analog output A1.
Unit of measurement: -
Options: 20MA = Output 0...20 mA
4-20M = Output 4...20 mA
10V = Output 0...10 V
2-10V = Output 2...10 V
C.20MA = Custom Output 0...20 mA
C.4-20 = Custom Output 4...20 mA
C.10V = Custom Output 0...10 V
C.2-10 = Custom Output 2...10 V
4.17.3. F.o.A1 - Selecting the function assigned to the analog output
Acronym Scrolling message Submenu Attributes
F.o.A1 REFERENCE SIGNAL ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the function assigned (retransmission of values) to analog output A1.
Unit of measurement: -
Options: NONE = No assigned function
HEAT = Heat control power
COOL = Cool control power
PV = Process variable
SSP = Active setpoint
SP = Local setpoint
SP-PV = Deviation |SP-PV|
SERIA = Value set from serial line
if the Programmer function is enabled:
SLV.SP = Slaved setpoint
4.17.4. LO.A1 - Scale minimum
Acronym Scrolling message Submenu Attributes
LO.A1 LOW LIMIT ANALOG OUTPUT OUT.AN R W
The parameter shows and sets the scale minimum, which corresponds to minimum output value in voltage or current.
Unit of measurement: Scale points of quantity assigned to analog output.
Options: -1999...9999
