9. TECHNICAL DATA
9. TECHNICAL DATA
OPERATOR INTERFACE 650 1250 1350
DISPLAY
Type LCD black background
Screen area (L x H) 35×30 mm 37×68 mm 83×68 mm
Lighting Backlit with LEDs, life > 40.000 hours @ 25 °C
* with brightness level BACKL=0.8
PV Display Number of digits: 4 to 7 segments, with decimal point
Digit height: 17 mm Digit height: 23 mm
Color: white or “custom”
SV Display Number of digits: 5 to 14
segments, with decimal
point
Digit height: 7,5 mm
Color: green or “custom”
Number of digits: 4 to 7
segments, with decimal
point
Digit height: 14 mm
Color: green or “custom”
Number of digits: 4 to 7
segments, with decimal
point
Digit height: 11 mm
Color: green or “custom”
F Display Number of digits: 5 to 14
segments, with decimal
point
Digit height: 9 mm
Color: ambra or “custom”
Number of digits: 7 to 14
segments, with decimal
point
Digit height: 9 mm
Color: ambra or “custom”
Unit of
measurement
Selectable, °C, °F or custom
1
Color: same as PV display
Controller state
signals
Number: 6 (RUN, MAN, _/-, REM, SP1/2) Color: ambra
Output state
signals
Number: 4 (1, 2, 3, 4)
Color: red
Bargraph indicator,
configurable
Type: graphic bargraph,11 segments
Power indication: 0...100% or -100...100%
Current indication: 0...100% f.s.
Valve position indication: 0...100%
KEYPAD
Keys number: 4, silicone ( Man/Auto, INC,DEC,F)
Type: mechanical
Keys number: 6, silicone
Type: mechanical
1) Programming is done with the GF_eXpress configuration program.
