4. CONFIGURATION
4.16.3. F.ou.x - Selecting the function assigned to relay, logic or Triac output
Acronym Scrolling message Submenu Attributes
F.ou.x OUTPUT FUNCTION OUTPU R W
The parameter shows and sets the function assigned to the output with identifying number “x”, if the output is relay, logic
or Triac and is direct or inverse.
Unit of measurement: -
Options: NONE = No assigned function
HEAT
= Heat control output
COOL
= Cool control output
ALRM1
= Output for Alarm 1
ALRM2
= Output for Alarm 2
ALRM3
= Output for Alarm 3
ALRM4
= Output for Alarm 4
OR.12
= Alarm 1 OR Alarm 2
OR.123
= Alarm 1 OR Alarm 2 OR Alarm 3
O.1234
= Alarm 1 OR Alarm 2 OR Alarm 3 OR Alarm 4
AND.12
=
Alarm 1 AND Alarm 2
AND.123
=
Alarm 1 AND Alarm 2 AND Alarm 3
AND.1234
=
Alarm 1 AND Alarm 2 AND Alarm 3 AND Alarm 4
AL.HB
=
Output for HB alarm
LBA
=
Output for LBA alarm
BUT.SR
=
Set/Reset from key
if the Timer function is enabled:
TIMER
= Timer state (end of count)
if the Programmer function is enabled:
P.HBB
= HBB alarm of programmer
P.RUN
= RUN state of programmer
P.HOLD
= STOP state of programmer
P.RDY
= READY state of programmer (after reset of time base)
P.END
= END state of programmer
EVENT
= EVENT state of programmer
if model with Logic Operations:
FB.OUT
=
Output of Function Blocks
if model with valve control:
V.OPEN
=
Output for the opening of the valve
V.CLOS
=
Output for the closure of the valve
if model with digital inputs:
IN.DIG
=
Repetition of a digital input
4.16.4. F.ou.C - Selecting the function assigned to continuous output
Acronym Scrolling message Submenu Attributes
F.ou.C REFERENCE SIGNAL CONTINUE OUTPUT OUTPU R W
The parameter shows and sets the function assigned to continuous output 1, direct or inverse.
Unit of measurement: -
Options: NONE = No assigned function
HEAT = Heat control output
COOL = Cool control output
PV = Process variable
SSP = Active setpoint
SP = Local setpoint
SP-PV = Deviation |SSp-PV|
SERIA = Value set from serial line
