80208G_MHW_650-1250-1350_01-2017_ENG

124

4. CONFIGURATION

4.23.1. but.1 - Selecting function key 1

Acronym Scrolling message Submenu Attributes

but.1 KEY FUNCTION HMI R W

The parameter shows and sets the function assigned to key 1 ( ) of the controller.

Unit of measurement: -

Options: NONE = No function assigned

AU-MA = Automatic-Manual control

LO-RE = Local-remote setpoint mode

HOLD = Hold main input value

AL.ACK = Reset alarm latches

S.TUNE = Activate Self-Tuning

A.TUNE = Activate Auto-Tuning

OUT.S.R = Set/reset outputs set with BUT.SR function

INT.RS = General reset

CAL.HB = Calibrate HB alarm

if the Multiset function is enabled:

SP.SEL = Select setpoint SETP1...SETP2

if enabled Options Logics

FB.IN = Input Function Blocks

4.23.2. but.2 - Selecting function key 2

Acronym Scrolling message Submenu Attributes

but.2 KEY FUNCTION HMI R W

The parameter shows and sets the function assigned to key 2 ( ) of the 1350 controller.

Unit of measurement: -

Options: As per but.1

4.23.3. but.3 - Selecting function key 3

Acronym Scrolling message Submenu Attributes

but.3 KEY FUNCTION HMI R W

The parameter shows and sets the function assigned to key 3 ( ) of the 1350 controller.

Unit of measurement: -

Options: As per but.1
