130
4. CONFIGURATION
4.24.1. STP.xx - Value of step xx
Acronym Scrolling message Submenu Attributes
STP.xx CUSTOM LINEARIZATION STEP LINRZ R W
The parameter shows and sets the value of the various steps, with xx from 0 to 32.
The start scale value goes in STP.00 and the full-scale value in STP.32.
The value of the nth step corresponds to the input: mV start scale + n*ΔmV con ΔmV = (mV full scale - mV start scale)/32.
Unit of measurement: Scale points
Options: -1999...9999
4.24.2. MV.STA - Setting mV at start of scale
Acronym Scrolling message Submenu Attributes
MV.STA MV START SCALE LINRZ R W
The parameter shows and sets the value in millivolts at start of scale if the input is a thermocouple.
Unit of measurement: mV
Options: -19.99...99.99
4.24.3. MV.FUL - Setting mV at full scale
Acronym Scrolling message Submenu Attributes
MV.FUL MV FULL SCALE LINRZ R W
The parameter shows and sets the value in millivolts at full scale if the input is a thermocouple.
Unit of measurement: mV
Options: MV.STA + 1...99.99
4.24.4. MV.50C - Setting mV at temperature of 50 °C
Acronym Scrolling message Submenu Attributes
MV.50C MV AT 50 ‘C LINRZ R W
The parameter shows and sets the value in millivolts at 50°C if the input is a thermocouple.
Unit of measurement: mV
Options: -1.999...9.999
