80208G_MHW_650-1250-1350_01-2017_ENG
115
4. CONFIGURA
TION
Acronym
Scrolling message
Password
Description
TIMER
TIMER MANAGER
Level 2
Lets you configure the timer parameters.
The submenu appears only if the Timer function was enabled
on the MODE submenu.
4.20.
TIMER Submenu – Configuring timer parameters
116
116
116
116
117
117
117
117
118
Selecting Timer
function mode
Parameter
page
Selecting the
Start/Stop timer
command
Defining the
Start/Stop timer
command logic
Selecting the
Reset timer
command
Defining the
Reset timer
command logic
Timer count
band
Selecting the
function acti-
vated at end of
count
Timer value
Message
assigned to
active Timer
F.tiM
St.St
S.S.t
rESE
rES.t
BAND
End
TIMER
MSG.TM
116
118
