102
4. CONFIGURATION
4.16.5. EVNT.N - Setting the event number
Acronym Scrolling message Submenu Attributes
EVNT.N EVENT NUMBER OUTPU R W
The parameter shows and sets the event number.
The parameter appears if the parameter F.ou.x = EVENT.
Unit of measurement: Number
Options: 1...4
4.16.6. FB.OU.N - Setting the Function Block output number
Acronym Scrolling message Submenu Attributes
FB.OU.N FUNCTION BLOCK OUTPUT NUMBER OUTPU R W
The parameter shows and sets the number of the Function Block assigned to the output.
The parameter appears if the parameter F.ou.x = FB.OUT.
Unit of measurement: Number
Options: 1...16
4.16.7. IN.DG.N - Setting the digital input number
Acronym Scrolling message Submenu Attributes
IN.DG.N DIGITAL INPUT NUMBER OUTPU R W
The parameter shows and sets the number of the digital input assigned to the output.
The parameter appears if the parameter F.ou.x = IN.DIG.
Unit of measurement: Number
Options: 1...2 Model 650 with option 2 digital inputs
1...3 Model 650 with option 3 digital inputs
1...5 Models 1250 and 1350 with option 5 digital inputs
4.16.8. SWTCH - Setting the number of switchings for signal
Acronym Scrolling message Submenu Attributes
SWTCH NUMBER OF SWITCHING CYCLES OUTPU R W
The parameter shows and sets the number of switchings (x1000) of the relay, exceeding which the signal is generated
OUTX.SWITCH ALARM where X is the number of output 1 or 2 or 3 or 4 if the output is relay, logic or triac.
The function is disabled if the parameter equals “0”.
Unit of measurement: Number
Options: 0...9999
4.16.9. FAULT - State of output with broken input
Acronym Scrolling message Submenu Attributes
FAULT FAULT OUTPUT STATE OUTPU R W
The parameter shows and sets the state (on, off) that the output assumes in case of broken input (Err, Sbr, ...), if the
output is direct or inverse.
Unit of measurement: -
Options: OFF = Output is off
On = Output is on
