4.6.11. SUB.SP - Setpoint value of slaved controller
Acronym Scrolling message Submenu Attributes
SUB.SP SUBDUED SETPOINT ASSOCIATED TO STEP PR.SPT R W
If the S.SP.EN function is enabled, the parameter shows and sets the setpoint value to be retransmitted as a percentage
of the controller setpoint value
EXAMPLE If the setpoint of the main controller is 180°C and you want the setpoint of the secondary controller to be
85°C, then SUB.SP should be set to 47.2 (47.2% of 180 is about 85).
Unit of measurement: %
Options: 0.0...100.0
4.6.12. S.RM.EN - Enabling ramp for slaved controller
Acronym Scrolling message Submenu Attributes
S.RM.EN SUBDUED SETPOINT RAMP ENABLE PR.SPT R W
If the S.SP.EN function is enabled, the parameter enables and disables the setpoint ramp for the slaved controller.
Unit of measurement: -
Options: OFF = Disables setpoint ramp for slaved controller
On = Enables setpoint ramp for slaved controller
4.6.13. ENBL.1 - Consent 1 to execute step
Acronym Scrolling message Submenu Attributes
ENBL.1 STEP ENABLE FOR STEP START PR.SPT R W
The parameter shows and sets consent 1 condition to enable execution of the step.
The consents automatically check that certain conditions have been met before the program continues.
There are 4 different consents (1, 2, 3 and 4) and, at the start of the step, the state of each must match the programmed
state.
Consents can be set via digital inputs, function block outputs, and the RS485 serial input.
If even one of the consents does not match the programmed state, the step is not executed.
If all consents are set to nonE, execution of the step is not conditioned and is always executed.
Unit of measurement: -
Options: nonE = Consent state is ignored, i.e., step is always executed
On = Consent must be on to execute step
OFF = Consent does not have to be on to execute step
4.6.14. ENBL.2 - Consent 2 to execute step
Acronym Scrolling message Submenu Attributes
ENBL.2 STEP ENABLE FOR STEP START PR.SPT R W
The parameter shows and sets consent 2 condition to enable execution of the step.
See ENBL.1 for details.
4. CONFIGURATION
