KEY
12. 40A fuse
14. Main fuses
15. Main relay
16. Key switch contacts
19. 1A diode
20. Key switch contacts
21. Auxiliary fuses
22. 12V - 14Ah battery
35. Stop button on rear brake
36. Stop button on front brake
38. Light switch
40. License plate bulb
42. Rear light
A. Stop light LEDs
B. Rear position light LEDs
45. Headlight
A. Front position light bulb
B. Low-beam light bulb
C. High-beam light bulb
54. Electronic ignition device (Vehicle connector)
67. Low-beam light relay
68. High-beam light relay
69. Resistance 120 Ohm - 2W
WARNING
ALL CONTINUITY TESTS MUST BE CARRIED OUT WITH THE CORRESPONDING CONNECTORS
DISCONNECTED.
TAIL LIGHT CHECK
1) Check the bulbs and replace them as indicated in the bulb table.
2) Check fuse No. 4 and contacts «G» and «H» of the key switch.
3) Check the continuity of the cable harness between the battery, fuse box (fuse No. 4) and contacts
of the key switch.
4) Check fuse No. 10.
5) Check the continuity of the cable harness between the key switch, fuse box (fuse No. 10) and bulbs.
6) Check that the Black cables of the bulbs are earthed.
LOW-BEAM LIGHT CHECK
1) Check the bulb and, if necessary, replace it as indicated in the bulb table.
2) Check the working order of fuse No. 1.
3) Check contacts «A» and «B» of the key switch.
GP 800 i.e. Electrical system
ELE SYS - 43
