Flywheel magneto

MAGNETO FLYWHEEL

Code Action Duration

1 001173 Rotor - Replacement

2 001067 Stator - Removal and Refit-

ting

3 001058 Complete flywheel - Replace-

ment

4 001104 Start-up freewheel - Replace-

ment

GP 800 i.e. Time

TIME - 17
