- Undo the two screws indicated.

- Remove the supporting plate.

Refitting

- Fit the supporting plate on the steering tube.

- Align the plate following the indicated reference

so as to allow the upper fixing screw to fit into the

hole on the steering tube.

GP 800 i.e. Suspensions

SUSP - 7
