Keep the tie rod in position and screw the nut up
to the end of stroke.
The tool will drive the fixed part seat on the crank-
case and the movable part seat on the shaft, thus
obtaining the correct ceramic seal preloading.
- Screw the rotor. (anticlockwise thread).
Locking torques (N*m)
Water pump impeller 4 ÷ 5
- Fit the pump cover with a new gasket, lubricate
the gasket previously with petroleum jelly grease.
- Tighten the six cover screws to the prescribed
torque.
N.B.
TO AVOID DEFORMATION, DO NOT LUBRI-
CATE THE O-RING WITH PETROLEUM
GREASE.
Locking torques (N*m)
Water pump rotor cover 3 ÷ 4
GP 800 i.e. Engine
ENG - 103
