Gilera GP 800 i.e. - Side Stand Fitting; Side Stand Removal

Side stand
REMOVAL
- Remove the left footrest.
- Remove the two return screws and unscrew the
nut indicated.
- Slide off the pin and remove the side stand.
- Should the side stand button be replaced, undo
the two screws indicated and remove the footrest
support.
- Disconnect the connector, remove the two
clamps, undo the two connecting screws to the
chassis and remove the button.
FITTING
- Follow the removal steps but in reverse order and tighten to the prescribed torques.
Locking torques (N*m)
Screws fixing side stand button 6 Side stand bolt nut 37
- Grease with the recommended product.
Recommended products
AGIP GP 330 Grease (brake lever, throttle grip)
Calcium complex soap-based grease with NLGI 2; ISO-L-XBCIB2
