Rear shock-absorber

REAR SHOCK ABSORBERS

Code Action Duration

1 003007 Rear shock absorber - Re-

moval and Refitting

2 003078 Rear fork - Replac.

3 000601 Fork removal and fitting /

Bushings and spacer remov-

4 003125 Fork bolt - Replac.

5 003126 Fork guards - Replac.

6 003127 Eccentric - Replac.

GP 800 i.e. Time

TIME - 29
