Gilera GP 800 i.e. User Manual

Name Torque in Nm
Driven pulley nut 153 ÷ 187
Clutch ring nut 65 - 75
External transmission cover screws 5 ÷ 7
Internal transmission cover screws 11 ÷ 13
Air switch screw 3 ÷ 4
Air outlet grille screws 3 ÷ 4
FLYWHEEL COVER
Name Torque in Nm
Flywheel fixing nut 116 ÷ 128
Stator retainers 8 - 10
Screw fixing freewheel to flywheel 13 ÷ 15
Flywheel cover screws 11 - 13
CRANKCASE AND CRANKSHAFT
Name Torque in Nm
Starting ring gear retaining plate 3 ÷ 4
Engine crankcase coupling screws (M6) 11 ÷ 13
Engine crankcase coupling screws (M8) 25 ÷ 28
COOLING
Name Torque in Nm
Water pump rotor cover 3 ÷ 4
bleed screw 3 ÷ 4
Water pump impeller 4 ÷ 5
Screws tightening water pump gear protection
plate
3 ÷ 4
CHASSIS
Name Torque in Nm
Side stand bolt nut 37
Screws fixing side stand button 6
Screw fixing electric fan - radiator 2 ÷ 3
Screw fixing radiator - chassis 5 ÷ 7
Nut fixing silent-block plate - chassis 22 ÷ 25
Nut fixing silent-block plate 33 ÷ 41
Pin fixing nut - M14 124 ÷ 153
Pin fixing nut - M10 47 ÷ 52
Upper nut fixing engine support link rods - chassis 33 ÷ 41
Lower nut fixing engine support link rods - chassis 33 ÷ 41
Nut fixing head - exhaust manifold 16 ÷ 18
Centre stand front bolt nut 34 ÷ 39
Centre stand rear bolt nut 74 ÷ 81
Screw fixing silencer - muffler support arm 11
Screw fixing catalytic converter - catalytic convert-
er support
22 ÷ 24
Screw fixing muffler support arm - engine 24 ÷ 27
Silencer fixing screw 22
Manifold retainer clamp 16 ÷ 18
Characteristics GP 800 i.e.
CHAR - 14
