Gilera GP 800 i.e. User Manual

Specification Desc./Quantity
Sealing pressure Cap calibrated at 0.9 bar
THERMOSTAT
Specification Desc./Quantity
Type Wax-type, with deviator
Starts opening 85±2°C
ELECTRIC VENTILATION
Specification Desc./Quantity
Type With piston
Electric ventilation starts at 105°C
Electric ventilation stops at 100°C
WATER PUMP
Specification Desc./Quantity
Type Centrifugal
Control Gear on oil delivery pump
RADIATOR
Specification Desc./Quantity
Type Aluminium, with vertical circulation
EXPANSION TANK
Specification Desc./Quantity
Calibration Automatic bleeding, in parallel with the radiator
Electric fan check
- Connect the injection diagnostic tester and select the «ERRORS» function in this menu.
- Check the electric fan control circuit for failures.
Specific tooling
020460Y Scooter diagnosis and tester
- Select the «ACTIVE DIAGNOSIS» function in this menu and run a simulation of the electric fan op-
eration.
- If the electric fan is certainly efficient, check the ventilation start and stop temperatures.
- Select the «PARAMETERS» function in this menu to display the coolant temperature.
Electric fan starts: 105°C
Electric fan stops: 100°C
- If non-conforming values are detected, replace the injection ECU..
- If the analogue instrument temperature is close to the red zone, but the degrees indicated by the
diagnostic tester is below the electric ventilation temperature, check the temperature sensor on the
head and check the relevant injection circuit;
N.B.
THE ELECTRIC FAN TEMPERATURE AT 105° C CAN ONLY BE MANAGED BY A SYSTEM SUP-
PLIED WITH RECOMMENDED FLUID AND PRESSURISED AT 0.9 BAR.
Cooling system GP 800 i.e.
COOL SYS - 4
