- Place the bearing onto the special tool with a little
grease to prevent it from coming out.
- Install the new bearing using the special tool.
Specific tooling
020376Y Adaptor handle
020360Y Adaptor 52 x 55 mm
020363Y 20 mm guide
- Refit the seeger ring.
Removing the driven pulley
See also
Removing the driving pulley
Inspecting the clutch drum
- Check that the clutch bell is not worn or damaged.
- Measure the clutch bell inside diameter.
N.B.
CHECK THE ECCENTRICITY MEASURED, 0.2
MM MAX.
Characteristic
Max. value:
175.5 mm
Standard value:
175+0+0.2 mm
Removing the clutch
Remove the clutch together with the driven pulley using the specific tool.
CAUTION
WHILE PERFORMING THESE OPERATIONS, AVOID CONTACT WITH OIL OR GREASE WHICH
COULD MAKE THE FAYING SURFACES BETWEEN THE BELT AND THE HALF-PULLEYS SLIP-
PERY.
GP 800 i.e. Engine
ENG - 7
