Gilera GP 800 i.e. User Manual

Removing the driving pulley
- Remove the O-ring as shown in the photograph.
- Lock the driving pulley using the appropriate tool.
- Unscrew the fixing nut and collect the belleville
spring and the washer.
Specific tooling
020660Y Driving pulley lock
- Remove the roller container.
- Remove the driven pulley together with the belt.
Engine GP 800 i.e.
ENG - 16
