Crankcase - crankshaft - connecting rod
Inspecting the wrist pin
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
See also
Cylinder - piston assy.
Inspecting the piston
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
See also
Cylinder - piston assy.
Inspecting the piston rings
N.B.
TO MEASURE WEAR LIMITS AND COUPLING CLEARANCES, SEE THE SPECIFICATIONS CHAP-
TER.
See also
Piston rings
Removing the piston
- Fit the piston and pin onto the connecting rod,
aligning the piston arrow towards the engine di-
rection of rotation.
Engine GP 800 i.e.
ENG - 54
