Inspecting the driven sliding half-pulley
- Check that the belt contact surface is free from
wear.
- Remove the 2 inside sealing rings and the 2 out-
side O-rings.
- Measure the movable half-pulley bushing inside
diameter.
Characteristic
Maximum admissible diameter:
55.05 mm
Standard diameter:
55.00 +0.035 0.00 mm
Refitting the driven half-pulley bearing
- Install a new roller bearing using the special tool.
N.B.
PLACE THE BEARING WITH THE WRITINGS
AND THE EMBEDDED OIL GUARD FACING
OUTWARDS.
- Properly support the half-pulley to prevent damaging the threading.
If you are working on the driven pulley unit fully assembled, use the special tool.
Specific tooling
020478Y Punch for driven pulley roller casing
001467Y002 Driver for OD 73 mm bearing
GP 800 i.e. Engine
ENG - 11
