Gilera GP 800 i.e. User Manual

Characteristic
Bearing diameter on the engine crankcase:
12 + 0.034 -0.016 mm
N.B.
THE TORQUE LIMITER IS PROVIDED WITH 4 GEARS THAT HAVE THE FUNCTION OF CLUTCH
DRIVE PLATES.
Driven plates consist of 4 Belleville springs provi-
ded with grooved profiles; this assembly allows
transmitting torques below 100 Nm (10 kgm).
In case of incorrect start-up procedures, the torque
limiter prevents any kicks, resulting in inversion of
rotation direction of the crankshaft which would
impair the engine structure
The limiter assembly cannot be overhauled. In case of irregularities on the toothed discs, replace the
assembly.
Refitting the free wheel
- Make sure the free wheel contact surfaces are in good condition.
- Thoroughly clean the free wheel to remove LOCTITE residue.
- Degrease the threading of the holes in the free wheel and the clamping screws.
- Apply the recommended product to the end of the screws.
Recommended products
Loctite 243 Medium strength threadlock
Loctite 243 medium-strength threadlock
GP 800 i.e. Engine
ENG - 43
