- Pour oil in small quantities and wait until it is distributed throughout the engine before checking the
level through the right crankcase sight glass «G».
The oil must reach the "MAX oil level" reference mark on the corresponding sight glass «G» on the right
crankcase.
WARNING
PROCEED TO TOP-UP WITH ENGINE OIL WHILE THE ENGINE IS WARM.
DO NOT GO BEYOND THE "MAX" MARK ON THE CRANKCASE OR BELOW THE "MIN" LEVEL
MARK ON THE DIPSTICK TO AVOID SEVERE ENGINE DAMAGE.
Check
For oil level check:
- Keep the vehicle perfectly upright, with both
wheels on the ground.
- Remove cover «A» holding it and pulling it out.
- Unscrew the dipstick cap «B» and check that the
oil level exceeds the «MIN» mark.
In order to check oil level properly, keep the engine
running for about 2 minutes and then wait at least
5 minutes once the engine is off.
GP 800 i.e. Maintenance
MAIN - 11
