Splitting the crankcase halves
- Working from the transmission side, undo the six
screws «A» and collect the washers.
- Turn the support so as to operate on the flywheel
side.
- Undo the three nuts fixing it to the support, collect
the washers and remove the three centring bush-
ings.
- Undo the seven screws «B» and collect the cop-
per washers.
- Undo the twelve screws «C» and collect the
washers.
- Fit the specific tool on the flywheel-side crank-
shaft, being particularly careful that the tool match-
es the shaft perfectly.
CAUTION
FAILURE TO OBSERVE THIS RULE CAN DAM-
AGE THE MAIN BUSHINGS.
Specific tooling
020664Y Flywheel side crankshaft fitting tip
- Lubricate the external surface of the tip with petroleum jelly grease.
Engine GP 800 i.e.
ENG - 72
