86 Xenon/Granit User Guide
Scanner
Scanner Communication and Scanning
The following feedback is provided by the scanner and indicates communication
and scanning status.
Scanner Charge Pack Status
The following charge status feedback is provided by the scanner when the scanner
is out of the base and has been idle for 5 seconds.
* The number of scans was measured with a clearly printed UPC code in good light.
The approximate number of scans varies with changes in label quality, symbology,
and environmental factors.
Low Power Alerts
Low power alerts allow you to customize the scanner LEDs to flash in different pat-
terns when the scanner charge level is low. Use the bar codes that follow to cus-
tomize the settings for the power range being configured, the number of flashes
per alert, the interval between flashes, the number of alerts, and the interval
between alerts. The beeper can also be set to silent, or to sound with the flash pat-
terns.
LED Indication Beeper Indication Cause
Normal Operation
Red Flash None Charge pack low
Green Flash 1 beep Successful communication or linking
Red, blinking Razz or error tone Failed communication
Menu Operation
Green Flash 2 beeps Successful menu change
Red, blinking Razz or error tone Unsuccessful menu change
Scanner LED Scanner Beep
Charge
Level
Approximate
Expected Scans*
Yellow
3 sets of flashes
2 short beeps per flash 30% 100
Red
3 sets of flashes
2 short beeps per flash 10% 50
