314 Xenon/Granit User Guide
*Storage outside of this temperature range could be detrimental to battery life.
Granit 1920i Industrial DPM Scanner Product
Specifications
Pitch Angle +70° typical, 200 lux, EAN/UPC
Motion Tolerance: 30 inches per second typical on 13 mil UPC/EAN bar
code 8 in. from scanner nose
Symbol Contrast 1D codes 30% or greater (typical, 200 lux, 13 mil)
2D codes 40% or greater (typical, 200 lux, 20 mil)
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 7.6 in. (193mm)
Length 5.3 in. (134mm)
Width 2.9 in. (74.5mm)
Weight 11 oz. (312g)
Electrical
Voltage Requirements 4 - 5.5 VDC at input connector
Current Draw @5VDC:
Scanning
Standby
470mA, 2.35W
90mA, 0.45W
Power Supply Noise Rejection Maximum 100mV peak to peak, 10 to 100 kHz
Illumination LED 630 nm (red)
470 nm (blue)
Aiming:
Peak Wavelength Laser 650nm; maximum output 0.5mW
Optical Power Laser Maximum output 0.5mW
Environmental
Temperature Ranges:
Operating -22°F to +122°F (-30°C to 50°C)
Storage -40°F to +158°F (-40°C to 70°C)
Humidity 0 to 95% non-condensing
Mechanical Drop Operational after 50 drops from 6.5 feet
(1.98m) to concrete at 23°, -30°, and 50°C
Vibration Complies with MIL-STD-810G, Method 514.6, Annex
C
ESD Tolerance Up to 20kV direct air
Up to 8 kV contact discharge
Sealant Rating IP65
