Xenon/Granit User Guide 311
*Storage outside of this temperature range could be detrimental to battery life.
Granit 1980i Industrial Full Range Corded Scanner
Product Specifications
Environmental
Temperature Ranges:
Operating while not charging -4F to + 122F (-20C to 50C)
Operating while charging 41F to + 104F (5C to 40C)
Storage with battery* -4F to +95F (-20C to 35C) for storage up to 90
days
-4F to +68F (-20C to 20C) for storage up to 365
days
Storage without battery -40F to +158F (-40C to 70C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 6.5 feet
(1.98m) to concrete at 23°, -30°, and 50°C
Vibration Complies with MIL-STD-810G, Method 514.6, Annex
C
ESD Sensitivity Up to 20kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP65
Image Size 838 x 640 pixels
Scan Performance
Skew Angle +65°
Pitch Angle +45°
Motion Tolerance:
Streaming Presentation Trigger:
13 mil UPC
240 inches per second at 6.5 in. (16.5cm)
150 inches per second at 10 in. (25.4cm)
Symbol Contrast Grade 1.0 (20% or greater)
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 7.7 in. (195.6mm)
Length 5.2 in. (132.1mm)
Width 2.9 in. (73.7mm)
Weight 11.8 oz. (335g)
Electrical
Voltage Requirements 4 - 5.5 VDC at input connector
