310 Xenon/Granit User Guide
Granit 1911i Industrial Cordless Scanner Product
Specifications
Scan Performance
Skew Angle +65°
Pitch Angle +
45°
Motion Tolerance:
Streaming Presentation Trigger:
13 mil UPC
240 inches per second at 6.5 in. (16.5cm)
150 inches per second at 10 in. (25.4cm)
Symbol Contrast Grade 1.0 (20% or greater)
Parameter (Continued) Specification
Parameter Specification
Mechanical
Height 7.7 in. (195.6mm)
Length 5.2 in. (132.1mm)
Width 2.9 in. (73.7mm)
Weight 13.8 oz. (390g)
Electrical
Illumination LED:
Peak Wavelength 624nm + 18nm (red LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Optical Power Laser <1mW
Battery
Lithium Ion 2400 mAHr minimum
Number of Scans Up to 50,000 per charge
Expected Hours of Operation 14
Expected Charge Time 4.5 hours
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 330 ft. (100m) typical
Data Rate Up to 1 MBps
