260 Xenon/Granit User Guide
Y - Vertical Bar Code Offset
The vertical bar code offset allows you to offset the vertical center of the signature
capture area. Negative numbers indicate that the signature capture is above the
bar code, and positive numbers indicate that the area is below the bar code. Mea-
surements are in multiples of the minimum bar width
Example: .
RF Default Imaging Device
The scanner supports imaging command processing (IMGSHP, IMGSNP, IMGBOX)
so that EZConfig-Scanning (see page 263) and other applications are able to per-
form imaging functions as if they were communicating directly with a scanner. To
accomplish this, the scanner uses a menu command called RF_DID (RF Default
Imaging Device). RF_DID is the name of the scanner (BT_NAM) that is to receive
imaging commands. The default for RF_DID is “*”indicating that imaging com-
mands are to be sent to all associated scanners. Change this setting to RF_DID-
scanner_name to ensure that they are sent to a particular scanner. Refer to
"Page" on page 3-54 to generate a report containing the port, work group, scanner
name, and address for each scanner. Refer to "Scanner Name" on page 3-68 set a
unique name for each scanner.
Vertical Offset set to -7Y:
Vertical Offset set to 65Y:
