Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
2 NE40E-X16 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
28
Item
Description
reliability
MTTR (hour)
0.5
Ambient
temperature
Long-term
0°C to 45°C ( 32°F to 113°F )
Short-term
-5°C to 55°C ( 23°F to 131°F )
Remarks
Limit of the temperature change rate: 30°C
( 86 °F )/hour
Storage temperature
-40°C to 70°C ( -40°F to 158°F )
Relative humidity
Long-term
5% RH to 85% RH, no coagulation
Short-term
5% RH to 95% RH, no coagulation
Storage humidity
0% RH to 95% RH, no coagulation
Long-term altitude
Lower than 3000 m ( 9842.4 ft )
Storage altitude
Lower than 5000 m ( 16404 ft )
As shown in the table, "width" does not involve the size of rack-mounting ears.
The measurement point of the temperature and humidity is 1.5 m ( 4.92 ft )over the floor and 0.4 m
( 1.31 ft ) in front of the cabinet without the front and the back doors.
Short-term operation means that the continuous operation time does not exceed 48 hours and the
accumulated operation time per year does not exceed 15 days. Otherwise, it is called long-term
operation.
Table 2-19 lists the typical configuration of the NE40E-X16.
Table 2-19 Typical configuration of the NE40E-X16
Platform
Description
40G
4*Fan+8*DC
Power+2*MPU+4*SFU+16*LPUF40+32*2-Port10GE FPIC
100G
4*Fan+8*DC
Power+2*MPU+4*SFU200B+16*LPUF100+32*5-Port10GE FPIC
2.6.2 Board Specifications
Table 2-20 lists the specifications of boards supported by the NE40E-X16.
Table 2-20 Specifications of boards supported by the NE40E-X16
Type
Description
Silkscreen
MPU
MPU
MPU
SFU
SFU
SFUI-40-B
