HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
3 NE40E-X8 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
48
Table 3-4 Technical parameters of the DC PEM
Item
Technical Parameter
Dimensions(Width x Depth x Height)
58mm x 115mm x 220mm ( 2.28 in. x 4.53
in. x 8.66 in. )
Weight
About 1.1 kg ( 2.43 lb )
Input voltage range
-38 V DC to -72 V DC
Input rated voltage
-48V/-60V
Maximum input current
70 A
Output voltage
-38 V DC to -72 V DC
Output current
70 A
Rated current of the air-break
70 A
3.2.4 AC Power Supply System
This section describes the appearance, functions, and the technical parameters of the AC
power supply module.
Figure 3-8 and Figure 3-9 show the appearance of the AC rectifier module.
Figure 3-8 Front view of the AC rectifier module
