Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
7 Cables
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
625
Item
Description
Fireproof class
CM
Available length
5 m ( 16.40 ft ) and 30 m ( 98.42 ft )
7.8 Optical Fiber
This section describes the structure and technical specifications of the optical fiber.
7.8.1 Introduction
Table 7-32 lists the types of optical fibers that the NE40E uses.
Table 7-32 Types of optical fibers
No.
Description
Local Connector
Remote Connector
Cable Mode
1
Fiber connecting
an interface board
to the ODF
LC/PC
FC/PC
Single-mode
2
Fiber connecting
interface boards
LC/PC
LC/PC or SC/PC
Single-mode
/multi-mode
3
Fiber connecting
an interface board
to another device
LC/PC
LC/PC or SC/PC
Single-mode
/multi-mode
The optical transmission module of the multi-transverse mode needs to be connected to the
multi-mode fiber. The optical transmitting module of the single-longitudinal mode or
multi-longitudinal mode needs to be connected to the single-mode fiber.
7.8.2 Optical Connectors
The NE40E uses the following types of optical connectors:

LC/PC optical connector

SC/PC optical connector

FC/PC optical connector
The outlines and operations of the connectors and the precautions that you should take when
plugging and unplugging the connectors are described in the following sections.
