Table A-17 Indicators of the DC-input power module
Indicates normal power input. If the indicator is on, there is an
input in the primary line.
If the indicator is on, the outputs of the primary and the
secondary lines are normal.
If the indicator is on, the output in the primary line is
abnormal, for example, less than the undervoltage value
(30 V DC to 34 V DC) or greater than the overvoltage
value (78 V DC to 80 V DC).
The secondary power output is abnormal because of the
power fan fault, overheated power module, or lightning
prevention circuit fault.
Table A-18 shows the indicators of the AC-input power module.
Table A-18 Indicators of the AC-input power module
Indicates normal power input. If the indicator is on, the
AC-input is normal.
Indicates normal power output. If the indicator is on, the
output voltage is in normal range.
Indicates power fault. If the indicator is on, the power module
has the following faults:
The power input is abnormal.
The power output is abnormal (such as over-voltage or
short circuit).
The fan of the power is abnormal.
The power module is overheated.
A.4.3 SRU Indicators
Table A-19 lists the status and descriptions of SRU indicators.
Table A-19 SRU indicators
If the indicator is on, you can remove a board.
If the indicator blinks once every 2s (0.5 Hz), the system
is in the normal state. If the indicator blinks twice every
1s (2 Hz), the system is in the alarm state.
