Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
C List of Interface Attributes
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
676
Attributes
Description
Center wavelength
1310 nm
1550 nm
1550 nm
Minimum
transmitting
power
-6.0 dBm
-1.0 dBm
0 dBm
Maximum
transmitting
power
-1.0 dBm
2.0 dBm
4.0 dBm
Receiving
sensitivity
-11.0 dBm
-15.0 dBm
-24.0 dBm
Overload power
0.5 dBm
-1.0 dBm
-7.0 dBm
Optical fiber type
Single-mode
Single-mode
Single-mode
The 10G XFP multi-mode optical transceiver supports two types of multi-mode optical fibers
with different cores. Table C-26 lists the relationship between the core, the modal/bandwidth,
and the transmission distance. During configuration, the length of optical fibers is restricted
by the transmission distance. In addition, the optical fiber with the 50-um core and
2000-MHz*km modal/bandwidth is a special type, which is not delivered by Huawei. If this
type of optical fibers are required, you need to purchase it additionally.
Table C-26 The transmission distance of 10G XFP optical modules
Core Fiber(μm)
Modal/Bandwidth(Mhz*
km)
Transmission
distance(km)
50
2000
2 ~300 ( 1.24 ~ 186.42 )
50
500
2 ~82 ( 1.24 ~50.95 )
62.5
200
2 ~33 ( 1.24 ~ 20.51 )
C.14 Interface Attributes of OC-768c/STM-256c POS-LC
Table C-27 lists the interface attributes of OC-768c/STM-256c POS-LC.
Table C-27 Interface attributes of the OC-768c/STM-256c POS-LC
Attributes
Description
Connector type
LC
Compliant standard
STM-256c/OC-768c SONET
Link protocol
PPP and HDLC
