If the power supply distance is longer than 50 m ( 164.04 ft ) , you need to place the power
distribution cabinet near the NE40E.
7.2.2 NE40E-X8 AC-input Power Cable
If the distance between an AC-DC convertor and a chassis is shorter than 3 m ( 9.84 ft ), use
the AC power cable shown in Table 7-13.
Table 7-13 Cable types and cable terminals of the AC-input power cable
Monitor and Alarm Cable,3m,D9M,CC4P0.48B(S),D9M
Wire,450/750V,227 IEC 02(RV)16mm^2,blue,85A
Wire,450/750V,227 IEC 02(RV)16mm^2,black,85A
Naked Crimping Terminal,JG2,16mm^2,M6,95A,Tin Plated,for
OEM
If the distance between an AC-DC convertor and a chassis is shorter than 50 m ( 164.04 ft ),
use the AC power cable shown in Table 7-14.
Table 7-14 Cable types and cable terminals of the AC-input power cable
Power Cable,300/500V,60227IEC10(BVV),6mm^2,Black
Jacket(Cores:Blue,Brown),43A,2 Equivalent Cores
Naked Crimping Terminal,OT,6mm^2,M6,Tin Plating,Insulated
Ring Terminal,12~10AWG,yellow
Naked Crimping Terminal,OT,6mm^2,M8,Tin Plating,Insulated
Ring Terminal,12~10AWG,yellow
If the power supply distance is longer than 50 m ( 164.04 ft ), you need to place the power
distribution cabinet near the NE40E.
7.2.3 NE40E-X3 AC-input Power Cable
Table 7-15 lists the type of the AC-input power cable.
