Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
7 Cables
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
624
Table 7-29 Pin assignments of the crossover cable
Connector X1
Connector X2
Color
Relationship
X1.6
X2.2
Orange
Twisted
X1.3
X2.1
White/orange
X1.2
X2.6
Green
Twisted
X1.1
X2.3
White/green
X1.4
X2.4
Blue
Twisted
X1.5
X2.5
White/blue
X1.8
X2.8
Brown
Twisted
X1.7
X2.7
White/brown
7.7.3 Technical Specifications
Table 7-30 and Table 7-31 show the technical specifications of the straight-through cable and
crossover cable respectively.
Table 7-30 Technical specifications of the straight-through cable
Item
Description
Connector X1/X2
Network port connector-crystal
connector-8PIN-8bit-shield-plug-24-26AWG-CAT 6/SFTP network
cable
Cable type
Communication cable-100±15ohm-shielded enhanced 5
types-CAT5E SFTP 24AWG-8 core PANTONE 445U
Number of cores
8
Fireproof class
CM
Available length
5 m ( 16.40 ft ), 10 m ( 32.81 ft ), 20 m ( 65.62 ft ), and 30 m ( 98.42
ft )
Table 7-31 Technical specifications of the crossover cable
Item
Description
Connector X1/X2
Network port connector-crystal
connector-8PIN-8bit-shield-plug-24~26AWG-CAT 6/SFTP network
cable
Cable type
Communication cable-100±15ohm-shielded enhanced 5
types-CAT5E SFTP 24AWG-8 core PANTONE 646U
Number of cores
8
