Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
7 Cables
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
611
Table 7-10 Cables for Power Distance More than 25 m ( 82.02 ft ) but Less than 35 m ( 114.83 ft )
Item
Description
Terminal
Bare crimping terminal-JG2-35mm^2-M8-210A- tin plating-OEM
Bare crimping terminal-OT-35mm^2-M8-tin plating
Cable type
Power cable -450V/750V-227 IEC 02(RV)-35mm^2-blue-135A
Power cable -450V/750V-227 IEC 02(RV)-35mm^2-black-135A
7.2 AC-input Power Cable
This section describes the structure and technical specifications of the AC-input power cable.
7.2.1 NE40E-X16 AC-input Power Cable
If the distance between an AC-DC convertor and a chassis is shorter than 3 m ( 9.84 ft ), use
the AC power cable shown in Table 7-11.
Table 7-11 Cable types and cable terminals of the AC-input power cable
Item
Description
Cable Type
Monitor and Alarm Cable,3m,D9M,CC4P0.48B(S),D9M
Wire,450/750V,227 IEC 02(RV)16mm^2,blue,85A
Wire,450/750V,227 IEC 02(RV)16mm^2,black,85A
Terminal
Naked Crimping Terminal,JG2,16mm^2,M6,95A,Tin Plated,for
OEM
If the distance between an AC-DC convertor and a chassis is shorter than 50 m ( 164.04 ft ),
use the AC power cable shown in Table 7-12.
Table 7-12 Cable types and cable terminals of the AC-input power cable
Item
Description
Cable Type
Power Cable,300/500V,60227IEC10(BVV),6mm^2,Black
Jacket(Cores:Blue,Brown),43A,2 Equivalent Cores
Terminal
Naked Crimping Terminal,OT,6mm^2,M6,Tin Plating,Insulated
Ring Terminal,12~10AWG,yellow
Naked Crimping Terminal,OT,6mm^2,M8,Tin Plating,Insulated
Ring Terminal,12~10AWG,yellow
