Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
7 Cables
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
617
7.5.3 Technical Specifications
Table 7-21 lists the technical specifications of the AUX interface cable.
Table 7-21 Technical specifications of the AUX interface cable
Item
Description
Connector X1
Network interface connector-crystal connector-8PIN-8bit-shielded plug
Connector X2
Cable connector-D type-25PIN-female
Connector X3
Cable connector-D type-9PIN-female
Cable type
Symmetrical twisted
cable-120-ohm-SEYVPV-0.5mm-24AWG-8core-PANTONE 430U
Symmetrical twisted
cable-100-ohm-SEYVP-0.48mm-26AWG-8core-black
Number of
cores
8
Fireproof class
CM
Available
length
15 m ( 49.21 ft ) for the 120-ohm cable
3 m ( 9.84 ft ) for the 100-ohm cable
7.6 Clock Cable
This section describes the structure and technical specifications of the clock cable.
7.6.1 Introduction

Clock cable for a common MPU/SRU
One end of the clock cable is an SMB connector connected to the clock interface on the
SRU/MPU and the other end is connected to the clock interface on an external device.
The connector on the other end needs to be prepared as required on site.
There are two types of clock cables:
− 75-ohm clock cable
− 120-ohm clock cable

Clock cable for the 1588v2-supporting SRU/MPU
A clock cable is used to connect the clock interface on the NE40E to the clock interface
on another device. In this manner, the NE40E can receive 2-Mbit/s clock signals, 2-MHz
clock signals, 1 PPS +ASCII time signals, 1 PPS+RS232 time signals, or two channels of
DCLS time signals from the upstream device and provides 2-Mbit/s clock signals,
2-MHz clock signals, 1 PPS +ASCII time signals, 1 PPS+RS232 time signals, or two
channels of DCLS time signals to the downstream device.
