D Optical Module
This chapter presents the optical module.
D.1 Instructions on How to Use an Optical Module
D.2 155 Mbit/s SFP/eSFP Optical Module
D.3 622 Mbit/s eSFP Optical Module
D.4 1 Gbit/s Electrical Transceiver
D.5 1.25 Gbit/s SFP/eSFP Optical Module
D.6 2.5 Gbit/s SFP/eSFP Optical Module
D.7 10 Gbit/s XFP Optical Module
D.8 10 Gbit/s XFP CWDM Optical Module
D.9 10-Gbit/s SFP+ Optical Module
D.10 10 Gbit/s SFP+ CWDM Optical Module
D.11 155 Mbit/s CSFP Optical Module
D.12 1.25 Gbit/s CSFP Optical Module
D.13 40Gbps TRANSPONDER Optical Modules
D.14 40Gbps CFP Optical Modules
D.15 100Gbps CFP Optical Modules
D.1 Instructions on How to Use an Optical Module
Use only the modules supplied by HUAWEI.We cannot guarantee that the interface module will operate
correctly if third-party transceivers are used.
Precautions for the loosened optical module
When installing an optical module, force it into position. If a crack sound is heard or a
slight tremor is felt, it indicates that the latch boss is secured. When the latch boss is not
secured, the connecting finger is unstably connected to the connector on the board, and
the link may become Up. On the condition that the optical module tremors or collides
