Primary I/O Drawer Operator Panel Behavior During Power-On
After Connecting ac Power (dc Power in a dc-powered System)
Drawer State Power LED Drawer Operator Panel Display
Standby Blinking slow 8xxx checkpoints followed by OK
System power ON Blinking fast
On solid
OK
9xxx checkpoints ending with E1FF
Receive firmware command On solid Exxx checkpoints ending with E105
Thereafter On solid 0xxx checkpoints ending with a blank
display
After Power is Removed Because of a Shutdown
Drawer State Power LED Drawer Operator Panel Display
Standby Blinking slowly OK is displayed
System power ON Blinking quickly
On solid
OK
9xxx checkpoints ending with E1FF
Receive firmware command On solid Exxx checkpoints ending with E105
Thereafter On solid 0xxx checkpoints ending with a blank
display
Critical error codes are posted on the top line (left-justified) of the drawer display with the attention light on
solid. Any location codes are posted on the bottom line (left-justified).
Noncritical error codes are not posted. The drawer display remains blank with the attention light on solid.
Chapter 1. Reference Information 27
