Appendix G. Rack Drawer Rail Instructions
This appendix provides information for installing rails into your rack or system.
Read the safety information in “Safety Notices” on page xi before using these procedures.
Front Drawer-Stop Installation
Install a drawer stop (2), part number 11K0358, on each side at the front of the rack to prevent the drawer
from sliding out the front. Use six screws (1), part number 73H2932, and four nut clips (3), part number
74F1823, to attach the drawer stops.
Note:
To put the drawer in the front-service position, the drawer stops have to be removed temporarily.
1
2
3
2
535
